Rockford Fosgate M5-800X4 800 Watt 4-Channel Element Ready™

General Features:

CEA-2006 Compliant: Yes

Number of Channels: 4

Total Power (Sum of Rated Power): 800 Watts

Rated Power (RMS Continuous Power) CTA-2006 GuidelinesCTA-2006 Continuous Power Rating

• 100 Watts x 4 @ 4Ω
• 100 Watts x 4 @ 2Ω
• 200 Watts x 2 @ 4Ω Bridged/Mono
• ≤1.0% THD+N

Dynamic Power (PVC/Power Cube®) CTA-2006 GuidelinesCTA-2006 Dynamic Power Rating

• 125 Watts x 4 @ 4Ω
• 200 Watts x 4 @ 2Ω
• 400 Watts x 2 @ 4Ω Bridged/Mono
• ≤0.25% THD+N

Bridgeable: Yes

Frequency Response: 10 Hz - 50 kHz

Input Sensitivity: 150 mV - 12 V

Circuit Topology Class: Class-AD

Efficiency (average) >75%

Total Harmonic Distortion (THD+Noise)

• <1.0% (Continuous)
• <0.25% (Dynamic)

Signal Input Low-Level: 4 RCA

• High-Level: (2) 4-Pin Molex)

Signal Output-

Tone Controls High Pass: 12.5 kHz @ 14dB/Octave Butterworth

Low Pass: 45 Hz @ 18dB/Octave Butterworth

Crossover Controls High-Pass:

• 50 Hz - 250 Hz @ 12dB/Octave Butterworth
• Low-Pass: 50 Hz - 250 Hz @ 12dB/Octave Butterworth

All-Pass: Yes

Remote Controls: No

Visual Indicators Power: Blue

• Protect: Red
• Input Clip: Red
• Output Clip: Blue/Red

Power Wire Gauge: 8 AWG

Power Input Connector Compression Terminal Block

Speaker Wire Gauge: 16 AWG

Speaker Output Connector: 4-pin Molex to tinned bare wire

Cooling: Convection

Heatsink: Extruded Aluminum

Operating Voltage: 9 - 16 VDC

Recommended Fuse:  (not included) 100 A

Average Current Draw (13.8V Music) 29 A

• Max. Current Draw (13.8V Sinewave)
• 55 A @ 4Ω
• 85 A @ 2Ω
• 90 A @ 4Ω Bridged

Suggested Alternator

Dimensional Diagram

Dimensions (H x W x D)

• 1.7" x 4.25" x 8.41"
• (42.8 mm x 108 mm x 213 mm)

Does not include harnesses

This unit is manufacturer Refurbished, Unit appears in a brown box, and is guaranteed to work perfectly. Some items may have cosmetic blemishes which will not affect the units ability to operate. This Unit Comes with ALL accessories supplied by the manufacturer and includes a 90 day warranty.
